PhytoMAX Power and Data Options
All PhytoMAX-3 and PhytoMAX-4 series lights can be connected to a dimming controller to control the lights; locking, waterproof dimming data cables and connectors are used for these connections.
Locking, watertight power cables and connectors are available for PhytoMAX-4 SC, PhytoMAX-3 SP, and PhytoMAX 3 SC series of LED grow lights. Up to 20 amps of lights may be connected on a single daisy-chain connection. Contact us for help selecting the best power configuration for your project.
PhytoMAX Data (Dimming) Cords
These data cords can be used with PhytoMAX SP, SC and SX models to connect the lights to a 0-10V dimming controller.
20 AWG Pigtails to PhytoMAX Waterproof Locking Data Female
PhytoMAX Waterproof Locking Data Male to PhytoMAX Waterproof Locking Data Female
Available in various lengths, these cords can be used as extension cords, or with Data Tees to daisy-chain the dimming signal to multiple lights.
PhytoMAX Waterproof Locking Data Tee (Male x Female x Female)
Used to daisy-chain the dimming signal to multiple lights.
PhytoMAX SC Power Cords
These power cords can be used with PhytoMAX SC models to connect the lights to 100-277V, 50/60Hz AC power.
NEMA 5-15P (North American 100-120V) to PhytoMAX Waterproof Locking Power Female
NEMA 6-15P (North American 208-240V) to PhytoMAX Waterproof Locking Power Female
NEMA 7-15P (North American 277V) to PhytoMAX Waterproof Locking Power Female
NEMA L7-15P (North American locking 277V) to PhytoMAX Waterproof Locking Power Female
20 AWG Pigtails (100-277V) to PhytoMAX Waterproof Locking Power Female
PhytoMAX Waterproof Locking Power Male (100-277V) to PhytoMAX Waterproof Locking Power Female
Available in various lengths, these cords can be used as extension cords, or with Power Tees to daisy-chain power to multiple lights, up to 20 amps total.
PhytoMAX Waterproof Locking Power Tee (Male x Female x Female)
Used to daisy-chain power to multiple lights, up to 20 amps total.
